Mitsubishi; FX3G-24MR/ES-A : PLC
PRODUCT DESCRIPTION: Compact PLC Dimensions W x H x D: 90 x 90 x 86 mm Inputs: 14 Digital, 6 High Speed Counter Inputs, abbreviated: 14 DI, 6 HS Operating temperature: 0...+55 °C Outputs: 10 Relay Outputs, abbreviated: 10 RO Internal program memory: 32 000 Schritte Operating voltage: 100-240 VAC Processing time per binary statement: 0.21 µs oder 0.42 µs Series: FX3G Protection rating: IP10 No. of digital inputs: 14 No. of high speed counter: 6 No. of relay outputs: 10
TECHNICAL ATTRIBUTES:
|
Physical
|
|
| Case/Package | Module |
| Mount | DIN Rail |
|
Technical
|
|
| Max Operating Temperature | 50 °C |
| Min Operating Temperature | 0 °C |
| Number of Inputs | 14 |
| Number of Outputs | 10 |
| Operating Supply Voltage | 240 V |
| Output Current | 8 A |
|
Dimensions
|
|
| Depth | 86 mm |
| Length | 90 mm |
| Width | 90 mm |
|
Compliance
|
|
| IP Rating | IP10 |
| RoHS | Compliant |
