Mitsubishi; HF-KP23B : Servo Motor

  • $835.00


  • Manufacturer : Mitsubishi Electric

  • HF-KP23B Series name : MELSERVO-J3 series

  • Command interface : SSCNET III Interface SSCNET III (Full Closed Control) General - purpose Interface Built-in CC-Link Corresponding Positioning Function

  • Voltage class : 200V

  • Rotary servo motor model name : HF-KP23B

  • Corresponding servo amplifier CC-Link IE field network interface : -

  • SSCNET III / H interface : -

  • 2 axes integrated SSCNET III / H interface : -

  • Three axis integrated SSCNET III / H interface : -

  • Generic interface : MR-J3-20A, MR-J3-20A1

  • SSCNET III interface : MR-J 3 - 20 B, MR-J 3 - 20 B 1

  • SSCNET III (full closed control) : MR-J3-20B-RJ006, MR-J3-20B1-RJ006

  • Built -in CC-Link compatible positioning function : MR-J3-20T , MR-J3-20T1

  • 2 axes integrated SSCNET III interface : MR-J 3 W-22 B, MR-J 3 W-44 B

  • Power supply capacity[kVA] : 0.5

  • Continuous characteristic Rated output [kW] : 0.2

  • Continuous characteristic Rated torque[N · m] : 0.64

  • Maximum torque (at torque up)[N · m] : 2.23

  • Maximum torque [N · m] : 1.9

  • Rated rotation speed [r / min] : 3000

  • Maximum rotation speed [r / min] : 6000

  • Instantaneous allowable rotational speed [r / min] : 6900

  • Power rating at continuous rated torque [kW / s] : 16.9

  • Rated current [A] : 1.4

  • Maximum current (at torque up) [A] : 4.9

  • Maximum current [A] : 4.2

  • Regenerative brake frequency [Times / min] : 448

  • Moment of inertia J [× 10 -4kg · m 2] : 0.31

  • Recommended load inertia moment ratio : 24 times or less

  • Speed ??/ position detector : Absolute incremental shared 18-bit encoder (Resolution per servo motor revolution: 262144 p / rev)

  • Equipment : - (Motor with oil seal is also available (HF - KP ? J))

  • Insulation class : Class B

  • Construction : Totally closed self cooling (degree of protection: IP 65)

  • Environmental condition- Ambient temperature : 0 to 40 ° C (no freezing), storage: -15 to 70 ° C (no freezing)

  • Environmental condition - Ambient humidity : 80% RH or less (no condensation), Storage: 90% RH or less (no condensation)

  • Environmental condition - atmosphere : Indoor (not to be exposed to direct sunlight), corrosive gas, inflammable gas, oil mist, dust free

  • Environmental condition - elevation : 1000 m above sea level

  • Environmental condition - Anti-vibration : X: 49 m / s 2 Y: 49 m / s 2

  • mass [kg] : 1.6

  • About constraints : Since restriction items are not displayed at the time of specification comparison, please see the specification of each model.

  • Shipping Weight : 3 Kg
