Omron; NB5-TW00B : LCD Graphic Display
Technical Specifications
|
Physical
|
|
| Case/Package | Module |
| Mount | Panel |
|
Technical
|
|
| Backlight Type | LED |
| Display Type | LCD |
| Max Operating Temperature | 50 °C |
| Min Operating Temperature | 0 °C |
| Number of Ports | 4 |
| Operating Supply Voltage | 27.6 V |
| Resolution (height) | 234 pixel |
| Resolution (width) | 320 pixel |
| Touchscreen | Resistive |
| Voltage Rating (DC) | 24 V |
|
Dimensions
|
|
| Depth | 1.567 inch |
| Diagonal Size | 5.6 inch |
| Length | 6.709 inch |
| Width | 5.079 inch |
|
Compliance
|
|
| IP Rating | IP65 |
| RoHS | Compliant |
